CENTRO 2PC High Platform Threaded Ball Valve is designed with ISO5211 for easy installing driving device. The ball valve has simple structure, light weight, easy installation , fast maintenance and various connection ends are suitable to pipe connections. CENTRO professional management team is expectiong for your valuable inquiries and co-operation.
CENTRO 2PC High Platform Threaded Ball Valve focus on customer and market’s demands, quick delivery available, accept sample ordering for testing requirements. Its top quality and reasonable price get share of the market as well as confidence . The products strictly conform to NPT / BSPT / BSP / DIN2999
Material available: SS316 SS304 SS304L 33316L, WCB
Suitable Mediums: Chemical, Water, Oil and Gas products etc.
- Full port, 1/2"~2" (DN15~DN50)
- Max Pressure:6.4MPa(PN64)
- W.T. : -20°C~200°C (-4°F~392°F)
- Investment casting
- Blow-out proof stemo
- Locking Device
- ISO5211 Direct Mounting Pad for Actuators
- Threaded ends conform to
- NPT / BSPT / BSP / DIN2999
|
NO |
Part Name |
Material |
|---|---|---|
|
1 |
Body |
WCB/CF8M/CF8 |
|
2 |
Ball |
SS316/SS304 |
|
3 |
Bonnet |
WCB/CF8M/CF8 |
|
4 |
Valve Cover Gasket |
SS304 |
|
5 |
Seat |
PTFE |
|
6 |
Seat |
SS304/SS316 |
|
7 |
Thrust Washer |
PTFE |
|
8 |
Stem Packing |
PTFE |
|
9 |
Junk Ring |
SS304 |
|
10 |
Handle |
SS304 |
|
11 |
Spring Wash |
SS304 |
|
12 |
Handle Nut |
SS304 |
|
13 |
Handle Lock |
SS304 |
|
NPS |
DN |
D |
L |
H |
H1 |
RA |
RB |
Ra |
Rb |
k |
|---|---|---|---|---|---|---|---|---|---|---|
|
1/2” |
15 |
15 |
62 |
38 |
9 |
18 |
21 |
3.0 |
3.0 |
9 |
|
3/4” |
20 |
20 |
75 |
41 |
9 |
18 |
21 |
3.0 |
3.0 |
9 |
|
1“ |
25 |
25 |
85 |
58 |
11 |
21 |
25 |
3.0 |
3.0 |
11 |
|
1 1/4” |
32 |
30 |
91 |
60 |
11 |
21 |
25 |
3.0 |
3.0 |
11 |
|
1 1/2” |
40 |
38 |
105 |
75 |
14 |
25 |
35 |
3.5 |
4.5 |
14 |
|
2“ |
50 |
49 |
120 |
80 |
14 |
25 |
35 |
3.5 |
4.5 |
14 |
