2PC Casting Steel Ball Valve

CENTROFLOW Manufactured and Distributed 2PC Casting Steel Ball Valve is made of investment casting which are also made by our own foundry. Using qualified raw material, valve parts, advanced test equipment and standardization operation, the full production process followed with ERP management, thus further secure the delivered products to reach or exceed our customer’s requirements. For more details please contact us, CentroFlow working team is pleased to serve you at your convenience.

Send Inquiry    PDF Download

Product Description

China OED/ODM supplier CENTROFLOW 2PC Casting Steel Ball Valve Flanged connections are good for minimal leakages for larger and small pipe sizes. Simple to install, replace, and easy to maintain. CentroFlow’s experienced and skilled workers makes our 2PC casting steel valve meet the most critical applications, receiving a good reputation in the market in past years. Sizes range from ½” to 8” with ASME Class 150/300 flanges. Material fully tested and controlled before production, during processing, before delivery. And additional certificated can be asked like TUV AD2000. BV certificated API.

CENTROFLOW 2PC Casting Steel Ball Valve Features

Size Range: ½”– 10”
CF8M or WCB Bodies/316SS Trim
Fire Safe Design Approved
ISO 5211(option)
Anti-Static Devices
Blow-out Proof Stem
Design: ASME B16.34, API 608
Wall Thickness:ASME B16.34 EN12516-3
Flange: ASME B16.5
Inspection and Testing: API 598 EN12266
W.T: -20 Deg C to 120 Degree

Material and Main Parts

NO.

PART NAME

MATERIAL

1

BODY

CF8/CF8M

2

SEAT

PTFE

3

BALL

SS304/SS316

4

BOLT

SS/SUS304

5

GASKET

PTFE

6

NUT

SS/SUS304

7

CAP

CF8/CF8M

8

STEM

SS304/SS316

9

THRUSTWASHER

PTFE

10

PACKING

PTFE

11

GLAND

SS/SUS304

NPS

d

L

H

h

D

DI

D2

C

f

Z-0d1

0a

0b

0A

0B

K

1/2"

15

108

50

10

89

60.5

35

11

2

4-016

6

6

36

42

9

3/4"

20

117

55

10

98

70

43

11

2

4-016

6

6

36

42

9

1"

25

127

60

12

108

79.5

51

12

2

4-016

6

7

42

50

11

1 1/4"

32

140

65

12

117

89

64

13

2

4-016

6

7

42

50

11

1 1/2"

40

165

70

16

127

98.5

73

15

2

4-016

7

9

50

70

14

2"

50

178

80

16

152

120.5

92

16

2

4-019

7

9

50

70

14

2 1/2"

65

190

95

16

178

139.5

105

18

2

4-019

7

9

50

70

14

3"

80

203

105

19

191

152.5

127

19

2

4-019

9

11

70

102

17

4"

98

229

120

24

229

190.5

157

24

2

8-019

9

11

70

102

17
